Wheel sand washer

  • Feed Particle Size

  • Processing Capacity

  • Machinery Weight

  • Product Introduce
  • Advantages
  • Application & Case
  • Technical Parameters

Equipment Device

When working, driven by the impeller, the sand and gravel grind each other to remove the impurities covering the surface of the sand and gravel, and at the same time destroy the water vapor layer covering the sand, and complete the cleaning and impurity removal function in a strong water flow.
When working, the motor drives the impeller to rotate slowly after being decelerated by the V-belt, reducer and gear. The sand and gravel enter the washing tank from the feeding trough, roll over under the drive of the impeller, and grind each other to remove the impurities covering the surface of the sand and gravel. Destroy the water vapor layer covering the sand grains to facilitate dehydration; add water at the same time to form a strong water flow, promptly take away impurities and foreign objects with small specific gravity, and discharge them from the overflow washing tank to complete the cleaning effect.

Advantages & Highlights

  • Multiple functions

    Multiple functions, high cleanliness. The machine has three functions of cleaning, dehydration and grading. When working, the sand and gravel grind each other to remove the impurities covering the surface of the sand and gravel. Function.

  • Scope of application

    It is suitable for washing, grading, impurity removal and other operations in metallurgy, building materials, water and electricity industries.

  • Large processing power

    Large processing capacity and long service life. The output of the machine is as high as 180 tons/hour, and the cleaning and lifting and conveying are running at the same time.

  • Structural layout

    The good structure layout and effective sealing design of the machine enable the machine to be maintained without maintenance for a long time, durable, low water consumption and low working noise.

Application & Project

A new type of forehead crusher that has been optimally designed and manufactured in terms of structure, material selection, process, assembly, etc.

Technical Parameters

Model Screw diameter (mm) Tub length (mm) Selected size (mm) Capacity (t/h) Speed of screw (r/min) Water consumption (t/h) Motor power (kw) Weight (t) Dimension (mm)
XSD2610 2600 3220 ≤10 50 0.8 4-4.5 5.5 2.7 3220x2125x2800
XSD3016 3000 3810 ≤10 80 0.8 16.3 7.5 3.2 3400x3000x3300

You may also like

high-tech enterprises

Modern intelligent processing base integrating R&D, production and sales.
Shanghai Dongmeng Road and Bridge Machinery Co., Ltd. is located in Fengxian District, Shanghai. It is a modern China Wheel sand washer manufacturers and custom Wheel sand washer suppliers, specializing in R&D, production and sales of OEM/ODM Wheel sand washer factory. With a team of more than 200 middle and high vocational technical engineers, relying on the pioneering and enterprising spirit, the unremitting pursuit of product excellence and the advantages of Shanghai's industrial chain, it has rapidly grown into a production, processing and export base of mining machinery in China.
  • 0+ Year

    Industry Experience

  • 0

    Factory Space

  • 0+


  • 0+

    Sets of Equipment

  • 0+

    Global Business

video Player

Honor & Qualification

Technological innovation, excellence, ingenuity, and Commitment to global sustainable development.

  • 1
  • 2
  • 3
  • 4
  • 5

Latest Insights & NEWS

Our team of engineers has carefully polished and cast stationary and mobile production line solutions for many years.

Contact Us for Quotes and Prices!

Just let we know what you want, and we will get in touch with you as soon as possible!

Request A Quote

Industry Knowledge Extension

What is a wheel sand washer and how does it work?

A wheel sand washer, also known as a bucket wheel sand washer, is a type of sand washing equipment used for cleaning and removing impurities from sand and gravel materials. It consists of a rotating wheel with a series of buckets attached to it, which scoop up sand and gravel from the bottom of a sand trap or quarry pit and lift it to the top of the wheel where the material is washed and cleaned.

The process of operation of a wheel sand washer involves the following steps:

Loading: The sand and gravel materials are loaded into the bucket wheel sand washer through a conveyor belt or manually.

Washing: As the wheel rotates, the buckets scoop up the sand and gravel and lift them to the top of the wheel where they are washed and cleaned by water jets or sprays.

Discharging: The clean sand and gravel materials are discharged from the wheel sand washer through a discharge chute or conveyor belt.

Recirculating: The dirty water containing the impurities and fines is discharged into a settling pond or tank, where the solids settle to the bottom and the clean water is recirculated back to the wheel sand washer for reuse.

Overall, the wheel sand washer is an efficient and effective way to clean and remove impurities from sand and gravel materials, and it is widely used in construction, mining, and other industries where sand and gravel materials are used.

What are the benefits of using a wheel sand washer in different applications?

There are several benefits of using a wheel sand washer in different applications:

Efficient cleaning: The wheel sand washer is designed to clean and remove impurities from sand and gravel materials quickly and efficiently. The rotating wheel and buckets lift the material to the top where it is washed and cleaned by water jets or sprays, ensuring that even the smallest particles are removed.

Consistent quality: By removing impurities and cleaning the sand and gravel materials, the wheel sand washer helps to ensure that the final product is of consistent quality. This is especially important in applications such as construction and mining, where the quality of the materials can impact the overall performance and durability of the finished product.

Increased productivity: The wheel sand washer is an automated machine that can process large volumes of sand and gravel materials quickly, allowing for increased productivity and throughput. This can help to reduce labor costs and increase overall efficiency in different applications.

Reduced maintenance: The wheel sand washer is designed to be durable and low-maintenance, with minimal wear and tear on the machine itself. This can help to reduce maintenance costs and downtime, ensuring that the machine is always available when needed.

Versatile: The wheel sand washer can be used in a variety of applications, including construction, mining, and other industries where sand and gravel materials are used. It is also compatible with different types of sand and gravel materials, allowing it to be used in a wide range of applications.

Overall, the wheel sand washer is a versatile and efficient machine that offers several benefits in different applications. It can help to improve productivity, reduce maintenance costs, and ensure consistent quality in the finished product.

What safety precautions should be taken when operating a wheel sand washer?

When operating a wheel sand washer, it is important to follow safety precautions to ensure the safety of operators and prevent accidents. Some safety precautions to take include:

Wear appropriate personal protective equipment (PPE): Operators should wear appropriate PPE, such as safety goggles, gloves, and steel-toed boots, to protect themselves from potential hazards.

Read and follow the manufacturer's instructions: Before operating the wheel sand washer, read and follow the manufacturer's instructions carefully to ensure that the machine is used correctly and safely.

Keep the work area clean and organized: Keep the work area clean and organized to prevent slips, trips, and falls. Remove any debris or obstacles that may be in the way.

Do not overload the machine: Overloading the machine can cause it to malfunction and potentially cause accidents. Follow the manufacturer's recommendations for maximum load capacity.

Do not touch moving parts: Keep hands and clothing away from moving parts to avoid injuries. Never reach into the machine while it is in operation.

Shut off power before performing maintenance: Before performing any maintenance on the wheel sand washer, shut off power to the machine and follow lockout/tagout procedures to prevent accidental startup.

Regularly inspect the machine: Regularly inspect the machine for signs of wear and damage. If any issues are found, stop using the machine and perform repairs before using it again.

Provide proper training: Provide proper training to all operators to ensure that they know how to operate the machine safely and effectively.

By following these safety precautions, operators can help prevent accidents and ensure safe operation of the wheel sand washer.
